충전기,베터리 미포함 입니다

Vehicle Specs

Length:22.20 inches (563mm)

Front Track:10.60 inches (270mm)

Rear Track:10.60 inches (270mm)

Center Ground Clearance:4 inches (99mm)

Weight (w/o battery):7.38lbs (3.35kg)

Height (overall):10.89 inches (277mm)

Wheelbase:13.23 inches (336mm)

Approach Angle:70°

Departure Angle:52°

Breakover Angle:67°

Front Shock Length:4.33 inches (110mm)

Rear Shock Length:4.33 inches (110mm)

Front Wheels:2.2 x 1.34 inches (56 x 34mm)

Rear Wheels:2.2 x 1.34 inches (56 x 34mm)

Front Tires:5.3 x 2.14 inches (135 x 54mm)

Rear Tires:5.3 x 2.14 inches (135 x 54mm)

Hex Size:12mm

Speed Control:XL-5 HV

Motor (electric):21T Reverse Rotation

Transmission:2-speed Hi-Lo, Remote Shifting

Gear Pitch:32P

Differential Type:4 Gear, Remote Locking

Chassis Structure / Material:Steel Ladder Frame with Nylon Composite Crossmembers

Brake Type:Electronic “Hill Hold”

Drive System:Shaft Driven 4WD

Steering:Chassis Mounted Servo

Servo:2075X Metal Gear

Transmitter:TQi™ 2.4 GHz 4-Channel Transmitter

Receiver:6533

Skill Level:1

Battery Tray:158.75 L x 47 W x 23/26mm H

Motor Specs

Type:High-torque brushed motor

Size:550

Weight:390g (13.76oz)

Length:3.071” (78mm) overall length, 2.25” (57mm) can length, 1.532” (38.9mm diameter)

Turns:21T reverse rotation

Voltage:16.8V

ESC Specs

Input Voltage:6–7 Cells NiMH, 2–3s LiPo

Case Size:1.23” W x 2.18” D x 1.04” H

Weight:2.6oz (74g)

Motor Limit:21-turns (550 size)

On Resistance Forward:0.004 Ohms

On Resistance Reverse:0.004 Ohms

Peak Current - Forward:100A

Peak Current - Reverse:100A

Braking Current:60A

Continuous Current:18A

BEC Voltage:6.0 VDC

BEC Current:1A

Power Wire:14 Gauge / 5”

Input Harness Wire:26 Gauge / 14.5”

Transistor Type:MOSFET

PWM Frequency:1700Hz

Low Voltage Detection (LVD):2-Stage indicators, switchable (on or off)

Thermal Protection:Thermal Shutdown

Profile selection:

Sport Mode: 100% FWD, 100% brakes, 100% REV

Race Mode: 100% FWD, 100% brakes, no REV

Training Mode:* 50% FWD, 100% brakes, 50% REV

Trail Mode: 100% FWD, 100% Brake, 100% REV, Trail-Tuned Brake on Neutral

Crawl Mode: 100% FWD, 100% Instant REV, 100% Brake on Neutral

Single-button setup:Yes, Traxxas EZ-Set®
